Jansen Techniek

JCS Checkweigher

The ideal weighing solution for the food industry

Suitable for E-weighing

Measuring range from 50 – 4.000g or 0.15 - 20kg

Robust construction

Modular conveyor belt

Request a quote View brochure

Description

The JCS Checkweigher is the ideal solution for weighing products in the food industry. The robust, open construction and sturdy modular belts mean that the JCS Checkweigher is resistant to the most extreme production conditions and can be cleaned under high pressure. The JCS Checkweigher is not simply robust, it is also highly precise and comes with an OIML R51 Type approval from the NMI. Combined with the user-friendly software, it is ideally suited to E-weighing, approved weighings and internal control weighings.

Software

The JCS Checkweigher is operated using a user-friendly touchscreen. Programs can be easily created or amended and the data collected can be saved via a USB or ethernet connection in Excel format.

Custom checkweigher

In addition to the standard design, custom checkweighers including a metal detector combinatoin are also available. This provides you with one machine for the complete end-of-line inspection of your product. The JCS Checkweigher can also be supplied with a range of ejection systems.

Use cases

Bakery

Convenience

Fish

Fruit & vegetables

Meat

Poultry

Questions? Ask Gerard

Do you have a specific question about the JCS Checkweigher or would you like advice? I am happy to help you.

+31 6 5155 0580

gschuurman@jansencontrolsystems.nl

EXPLANATION VIDEO

Features of this machine

OIML R51 Type approval from the NMI

Approved software

Automatic reset

Automatic calibration

User-friendly touchscreen

Anti Floor Vibration loadcell

Robust frame with collision protection

Can be simply repositioned with a pump truck (hand pallet truck)

Range of ejection principles available

Specifications

ApplicationsE-weighing, calibrated weighing and control weighings

Measuring range50 – 4.000 g / 150 – 20.000 g

Weighing precision2 gram (in accordance with the Metrology Act)

Max. no. checks135 wpm (weighings per minute)

Max. no. recipes250 different products to be set

Max. speed84 m/min (depending on product, product length and product supply)

Belt typeModular acetal

Belt length680 mm

Belt width355 mm

ConstructionStainless steel 304 / plastic (FDA)

ProtectionIP67

Power230 V
